Fingerprint 125KHz Access Control Standalone Access Controller 200Fingers with Waterproof and Wiegand Input and Output

Description

Fingerprint Standalone Access Controller

Model No.: BF1161302262

What is stand-alone controller?

A standalone controller has the ability to perform all of its own engine monitoring and control functions from a single box. It does not require any outside assistance from the body or chassis modules. As such, they are particularly well suited to race cars, hot rods, and classics where these outside modules seldom exist

Product feature

> Metal case, anti-vandal

> Fingerprint access controller and reader, WG26 Input /output

> Capacity: 200 fingerprints and 500 cards

> Two accesses: card, fingerprint

Card type	EM
Working voltage	DC12V±10%
Reading Range	3-6cm
Humidity	20% to 90% RH
Door Opening Time	0-99s(Adjustable)
Sleep electricity	≤30mA
Static electricity	≤80mA
Electric lock output	≤3A
Short-circuit Protect	≤100μS
Dimensions	110x45x20mm

Fingerprint 125KHz Access Control Standalone Access Controller
Model No.	Dimension	Quantity/Carton	Gross Weight	Carton Size
F6EM	110x45x20mm	54pcs	19.3KG	55.5x40x39.9cm
F6EM-W	110x45x20mm	54pcs	20.4KG	55.5x40x39.9cm

Fingerprint Standalone Access Controller

Additional information

Brand	Bluefield
