Waterproof Metal Access Control Card Reader
> Card type: EM or MF Card
> Metal structure design, anti-vandal
> Digital backlit keyboard
> All-in-one, WG26 output/input
> Three-way to open the door, card, password, card + password
> The doorbell button and interface: buttons and isolation circuit, connect to any external bell
SHARE
Description
Waterproof Metal Access Control
Model No.: BF116130252
| Card type | EM or MF |
| Waterproof degree | Non-Waterproof(S603) / IP68(S603-W) |
| User capacity | 2000 card user card, 2000 user password |
| Environment Humidity | 10%～90% |
| Lock output | ≤3A |
| Working voltage | DC12V±10％ |
| Static electricity | ≤30mA |
| Alarm output | ≤20A |
| Output short circuit protection time | ≤100μS |
| Card read distance | 5～8cm |
| Ambient temperature | -45℃～60℃ |
| Door Opening Time | 0～99s(Adjustable) |
| Dimension | 123*58*20mm |
| Waterproof Metal Access Control Card Reader | ||||
| Model No. | Keypad | Quantity/Carton | Gross Weight | Carton Size |
| S603EM | Metal Keypad | 50pcs | 18.2KG | 44×29.5×25.5cm |
| S603MF | ||||
| S603EM-W | Metal Keypad | 50pcs | 20.7KG | |
| S603MF-W | ||||
| S603EM | Silicon Keypad | 50pcs | 16.7KG | |
| S603EM-W | Silicon Keypad | 50pcs | 19.2KG | |
Additional information
| Brand | Bluefield |
|---|
